External Threaded Pot Magnets 16x5mm

The Ø16 small external threaded pot magnets are made of rare earth neodymium, standard thickness is 5mm. There are M4 threaded pins on the steel shell, which make it mountable. You can get about 12 lb pull force by using external threaded neodymium pot magnets Ø16x5mm. In the pot magnets wholesale, cheap price and short lead time are available for Ø16mm neodymium external thread pot magnets.

Characteristics Of External Threaded Pot Magnets 16x5mm

Dimension: Diameter-16mm, thickness-5mm

Magnetic Core: Disc neodymium magnets

Magnetic Force: 12 lb vertical pulling force

Surface Treatment: With Ni-Cu-Ni plating

Specification Of External Threaded Pot Magnets 16x5mm


Category

Pot Magnets

Type

With External Threaded Pin - C16

Magnet&Grade

NdFeB-N35

Dimension

Ø16 x 5mm

Diameter

16mm

Thickness

5mm

Threaded Pin

M4x8

Coating

Nickel

Pull Force

5.5 kg

Tolerance

+/-0.1mm

Weight

7.5 g

Working Temp.

80℃
